Product Description
Rated Voltage:300V
Rated temperature: 150°C
Conductor: Tinned or bare, stranded or solid copper
Gauge: range from 30AWG to 10 AWG
Insulation: color coded XLPE (irradiated)
Flammability: pass UL H & CSA FT2 horizontal flame test
Uses standard thickness of insulation to ensure easy stripping and cutting
Resistant to heat, cold, oil and chemical solvent
Standard:UL758,UL1581, CSA C22.2 No.210.2
UL File No.:E487227 CUL File No.:E487227
Application
Internal wiring where not subjected to movement or mechanical damage (600V peak - for electronic use only).
Packing
Plastic spool,Plywood drum.
Color
