Product Description
Rated Voltage: 300V
Rated temperature: 80°C
Conductor: tinned or bare, stranded or solid copper
Gauge: range from 30AWG to 16AWG
Insulation: color coded PVC
Shield: tinned or bare copper wire spiral
Jacket: PVC
Uniform insulation thickness of wire to ensure easy stripping and cutting
Flammability: pass UL VW-1 & CSA FT1 vertical flame test
Standard: UL758,UL1581, CSA C22.2 No.210.2
UL File No.:E487227 CSA File No.:268104
Application
Internal wiring of appliances and electronic equipment.
Packing
Plastic spool,Plywood drum.
Color
