Product Description
Rated Voltage: 1000V
Rated temperature: 90°C
Conductor: tinned or bare,stranded or solid copper
Gauge: range from 30AWG to 10AWG
Insulation: color coded PVC
Flammability: pass UL VW-1 & CSA FT1 vertical flame test
Uniform insulation thickness of wire to ensure easy stripping and cutting
Resistant to acids, alkalis, oils, moisture and fungi
Standard: UL758,UL1581, CSA C22.2 No.210.2
UL File No.:E487227 CUL File No.:E487227
Application
Internal wiring of appliances(3500 Volts peak - for electronic use only).
Packing
Plastic spool,Plywood drum.
Color
